500W Solar Charge Inverter

  • 产品型号:WS-ACM500
  • 官方报价:0.0000
  • 品牌:10000
  • 产地:Whole sale
    01 02 03 04 05 06
    07 08 09 10 11 12
    全年

产品介绍:

WS-ACM500 500W Solar Charge Inverter Wellsee

Brand: WELLSEE

Category: Solar AC Charging Inverter

Model: WS-ACM500

Weight: 7.0kg

Size: 220*155*420 mm



WS-ACM500 500W WELLSEE solar charge inverter (solar inverter with charger) has delay startup function, which could prevent the high current impulse to battery and load. It (power inverterwith charger) also has the following settings such as imput over-voltage, imput under-voltage, output overload, output short circuit, overheat protection and so on. Voltage protection backlash is configured reasonably.

WS-ACM500 500W has a diversity of input and output ways: 12V input, 24V input, 36V input ,48V input; 220VAC output etc., which can meet the demand of both domestic and international users for mobile alternating current.

Functions:
1.Overload protection
2. Overcharge protection
3.Temperature protection
4.Low voltage protection
5. Short circuit protection
6.Converse connection protection


TECHNICAL INDEX :



Model

WS-ACM150(A/B)

WS-ACM180(A/B)

WS-ACM300(A/B)

WS-ACM600(A/B)

WS-ACM1000(A/B)

WS-ACM2000 (A/B)

WS-ACM3000(A/B)

Power

150W

180W

300W

600W

1000W

2000W

3000W

Input voltage

12V

12V

12V

12V

12V 24V

12V 24V

12V 24V

Output voltage

175V 270V

175V 270V

180V 260V

185V 255V

190V 250V

195V 245V

200V 240V

No load loss

≤0.5%

Output frequency

50 60Hz

Output wave

Modified Sine Wave



We are special large scale R&D and manufactory enterprise of solar power inverter  ,the global supplier of WELLSEE solar controller, photovoltaic system equipment . We also have passed ISO9001, CE and RoHS certifications. Wuhan Wellsee products can be designed and produced according to clients’ special request. Welcome to be our agents!

If any enquiry, please don't hesitate to contact me. Thanks.

Sara (e-mail: business@e-bluelight.com)
